| Selectable Frequency Range | Maximum selectable bandwidth | Maximum selectable output power |
|---|---|---|
| 2000-4000MHz | 100W |
*Note: The “Selectable Frequency Range” shown in this table refers to the manufacturing coverage, not the exact output range of a single module. Each module must operate within this range, with an actual output bandwidth that does not exceed the “Maximum Selectable Bandwidth.”
| Item | Indicator |
|---|---|
| Transistor | GaN |
| Operating Voltage | 28V |
| In-band fluctuation | ≤±2dB |
| Output VSWR | ≤2.50W |
| Operating temperature | -20～+65℃ |
| RF output connector | N-F |
| Module protection | Temperature Compensation, Over-temperature Protection, VSWR Protection |
*Special Disclaimer: Due to the transition period between product updates and online display, the image and text specifications on this page may differ from the actual product. The images and text on this page are not intended to be used as a basis for actual delivery. Specific product and technical specifications are subject to the actual product configuration. Interested buyers should contact Zorelock sales staff for confirmation. Zorelock reserves the right to modify image specifications and make final interpretations.
